1P

The STR_FR_1P is a south facing open field ground mount system with minimum clearance of 500 mm

TECHNICAL DATA

The STR_FR_1P is a south facing open field ground mount system with minimum clearance of 500 mm. The aerodynamic design and on-field ruggedness o ver decades stands testimony to the mounting systems strength.

Flat Roof On Industrial, Agricultural and Residential Buildings
Application Area

5 years
System Warranty

in-situ casted RCC PV Mounting System
System

Bitumen, Concrete, Gravel, Tiles
Roof Covering

SPECIFICATIONS OF THE PRODUCT

HDG / Galvalume

Durable, corrosion-resistant steel coating for construction and automotive. Recyclable and energy-efficient.

Non Penetrating

No drilling, preserves surface integrity. Quick, versatile, and compliant. Ideal for roofs, events, and more.

10 & 15 Degree

Solar panel tilt angles. 10° captures more winter sunlight. 15° balances year-round performance. Choose based on location and goals.

50m/s

Destructive storm speed. Causes damage, flying debris, power outages. Safety measures essential.

Additional information

System Orientation

South

Structure Tilt (º)

10º, 15º, 20º, 25º

Material

Hot Dipped Galvanized Steel or Pregalvanized

Minimum Ground Clearance

300 mm / 500 mm

Wind Speed

55 m/sec

Type

PV modules with frame height between 30-50 mm

Module Size (max)

Length: any; Width: any

Orientation

Single Portrait

Wind Load

Certified by ABS Industrial Verification (India) Pvt. Ltd.

Layout and Ballast Plan

Provided by Strolar®
