G Bracket

The STR_IR_SLFG is a south facing open field ground mount system with minimum clearance of 500 mm.

TECHNICAL DATA

The STR_IR_SLFG is a south facing open field ground mount system with minimum clearance of 500 mm. The aerodynamic design and on-field ruggedness over decades stands testimony to the mounting systems strength.

High Seam Roof
Application Area

5 years
System Warranty

Seam Roof PV Mounting System
System

High Seam Roof Shed of galvanised steel galvalume, zincalume or any similar make
Roof Covering

SPECIFICATIONS OF THE PRODUCT

HDG / Galvalume

Durable, corrosion-resistant steel coating for construction and automotive. Recyclable and energy-efficient.

Non Penetrating

No drilling, preserves surface integrity. Quick, versatile, and compliant. Ideal for roofs, events, and more.

10 & 15 Degree

Solar panel tilt angles. 10° captures more winter sunlight. 15° balances year-round performance. Choose based on location and goals.

50m/s

Destructive storm speed. Causes damage, flying debris, power outages. Safety measures essential.

Additional information

System Orientation

South

Structure Tilt (º)

Flush mounted

Material

Stanless Steel, Aluminium 6063 T6, EPDM

Type

PV modules with frame height between 30-50 mm

Module Size (max)

Length: any; Width: any

Orientation

Landscape

Wind Load

Certified by ABS Industrial Verification (India) Pvt. Ltd.

Rib Distance

Can be fit to any standard rib distance

Roof Slope

Maximum 15º
