U 100
Enhance solar efficiency with the compact and lightweight STR_IR_U100 Composite Aluminum Mounting System. Featuring a south-facing pitched roof design and 100 mm clearance, this system combines aerodynamic excellence with on-field ruggedness, making it the ideal choice for industrial and commercial sheet roof installations.
TECHNICAL DATA
The system's robust construction ensures longevity and reliability, making it an ideal choice for sustainable energy solutions. Elevate your solar infrastructure with the STR_IR_U100 and experience the perfect blend of form and function, delivering exceptional results for your industrial and commercial ventures.
Pitched metal sheet roofing
Application Area
Trapezoidal metal sheet made of steel and aluminium
Roof Covering
PV Mounting System for trapezoidal metal sheet
System
15 years
System Warranty
SPECIFICATIONS OF THE PRODUCT
Additional information
| Rib Distance | Length made available on request |
|---|---|
| Roof Slope | Maximum 40° |
| System Orientation | South |
| Structure Tilt (°) | Flush mount |
| Material | Stainless Steel, Aluminium 6063 T6, EPDM |
| Profile Height | 100 mm |
| Wind Speed | 55 m/sec |
| Type | PV modules with frame height between 30-50 mm |
| Module Size (max) | Length: any; Width: any |
| Orientation | Landscape |
| Wind Load | Certified by ABS Industrial Verification (India) Pvt. Ltd. |
| PV Layout | Provided by StrolarⓇ |
