U60
Revolutionize your solar installation with the STR_IR_U60 – a compact, lightweight, and durable composite aluminum mounting system. Tailored for south-facing pitched roofs, it features a minimal 60 mm clearance for optimal space utilization. The aerodynamic design and proven on-field ruggedness make the STR_IR_U60 the ideal choice for industrial and commercial scale sheet roof mounting systems.
TECHNICAL DATA
The STR_IR_U60 guarantees a secure and stable foundation, providing peace of mind for both short-term and long-term energy needs. Elevate your solar energy project with the confidence that comes from investing in a mounting system known for its resilience and efficiency – the STR_IR_U60.
Pitched metal sheet roofing
Application Area
15 years
System Warranty
PV Mounting System for trapezoidal metal Sheet
System
Trapezoidal metal sheet made of steel and aluminium
Roof Covering
SPECIFICATIONS OF THE PRODUCT
Aluminium 6063 T6
Pitched Roofing
Flushed Mount
55m/s
Additional information
| Rib Distance | Length made available on request |
|---|---|
| Roof Slope | Maximum 40° |
| System Orientation | South |
| Structure Tilt (°) | Flush mount |
| Material | Stainless Steel, Aluminium 6063 T6, EPDM |
| Profile Height | 60 mm |
| Type | PV modules with frame height between 30-50 mm |
| Module Size (max) | Length: any: Width: any |
| Orientation | Landscape |
| Wind Load | Certified by ABS Industrial Verification (India) Pvt. Ltd. |
| PV Layout | Provided by Strolar |
